Product Overview and Key Features
Specifications
Downloads (Coming Soon)
Included Accessories
- Incorporates a Universal Leveling Head that Locks into 4 Different Positions
- New Arm Design increases Vertical Travel and Rigidity
- Hardened Stainless Steel Bushings
- Compact and Lightweight for Travel and Storage
- Improved Arm System allows for up to 4 full Lifts on one charge
- Universal Stop Valve Allows Feathered Stops, as well as, Precise, Repetitive Moves
- Universal Stop Valve Allows Settings on Upper and Lower Stops
- New Control Valve Design is Faster and Quieter While Allowing Smooth Stops
- New Wheel Composition Allows increased Rigidity, as well as, Silent Operation on Track
- New Wheel Composition Allows Easier Steering and Maneuverability
- Special Off Road Wheel additional accessory for transport over rough terrain
- Works on Both Straight and Curved 24 1/2 Tubular Track or 880 mm Track
- Many Accessories Available
Carrying Weight
280 lb / 127 kg
Maximum Payload
250 lb / 113 kg
Maximum camera mount height (position 1 - 90º mode)
4 ft. 11 3/4 in. / 1.51 m
Minimum camera mount height (position 1 - 90º mode)
29 1/2 in. / 74.93 cm
Vertical boom travel (position 1 - 90º mode)
30 1/4 in. / 77 cm
Maximum camera mount height (position 2 - 45º mode)
4 ft. 9 1/2 in. / 1.46 m
Minimum camera mount height (position 2 - 45º mode)
25 1/2 in. / 65 cm
Vertical boom travel (position 2 - 45º mode)
32 in. / 81 cm
Maximum camera mount height (position 3 - low mode)
4 ft. 2 1/2 in. / 1.28 m
Minimum camera mount height (position 3 - low mode)
19 1/4 in. / 48 cm
Minimum Camera mount height with PeeWee 90º plate
3 in. / 8 cm
Vertical travel
2 ft. 7 in. / 79 cm
**Maximum payload with high post kit
1,100 lbs. / 499 kg
Maximum boom lifts (fully charged)
4 Lifts
Accumulator Charging Time (Empty to full)
60 sec.
Chassis maximum length (wheels fully extended)
3 ft. 7 in. / 1.09 m
Chassis minimum length (wheels fully retracted)
34 1/2 in. / 88 cm
Minimum chassis height for transportation
16 in. / 41 cm
Chassis width - legs at 0º position
20 in. / 51 cm
Chassis width - legs at 17º position (pneumatic tire position)
23 1/2 in. / 60 cm
Chassis width - legs at 45º position
2 ft. 4 1/2 in. / 72 cm
Chassis width - 90º (sideways/scissor track position)
2 ft. 8 in. / 81 cm
Steering post height
2 ft. 11 in. / 89 cm
Minimum turn radius
24 in. / 61 cm
Min door width dolly can be carried through
16 in. / 41 cm
Standard operational weight
329 lb / 149 kg
Operational weight with high post kit (no payload)
386 lb / 175 kg
Dolly Shipping Weight w/Crate
475 lb / 215.4 kg
Dolly Shipping Dimensions
L 43 in. x W 27 in x H 36 in.
Dolly Accessory Cart Shipping Weight w/Crate
346 lb / 156.9 kg
Dolly Accessory Crate Dimensions
L 44 in. x W 35 in. x H 28 in.
*Payload includes All Items (i.e. Man, Camera, Platform, Turret, Crane Arm, etc.) on Arm
**Payload includes All Items (i.e. Man, Camera, Platform, Turret, Crane Arm, etc.) on Base Mount.
Please view below for the equipment that is included as standard with a Super PeeWee III+ rental. Need more accessories? Check out our Full Package, or build your own Custom Package.
12" CAMERA RISER
CASTLE RING - MITCHELL
CAMERA DOLLY SEAT COMPLETE
12" DOLLY SEAT RISER-LONG POST
VALVE CONTROL HANDLE,PW-SPW 3+
FRONT BOARD, PW/SPW-SPW 3+
PEEWEE NARROW SIDEBOARD
LEVELING HEAD 4-1/2" RISE
NUT,SPW 3+/4/5 SWING HEAD ADJ
UNIVERSAL LOW PLATE,SPW 3+/4/5
UNIVERSAL WRENCH,SPW 3+/4/5
UNIVERSAL STOP VALVE,SPW 2/3+
MEDIUM TIRE, PW-SPW 5 SET (8)
